When your job site is defined by mud, gravel, or uneven surfaces, traditional wheeled lifts fall short. A tracked scissor lift for sale is the only way to overcome these challenges. It brings essential lift stability to rough terrain environments. Our tracked platforms are specifically designed for outdoor and heavy construction use.
Tracked Scissor Lift for Sale Parameter:
| Model | Up(m) | Load(kg) | Platform size(m) | Outline dimensions/guardrail folding(m) | Lifting motor | Weight(kg) |
| YG0608SP | 5.8 | 230 | 1.67*0.74 | 1.86*0.76*1.84 | 24v/3.3kw | 1580 |
| YG0608 | 6 | 450 | 2.27*1.12 | 2.48*1.19*1.66 | 24v/3.3kw | 2170 |
| YG0810NP | 8 | 230 | 2.27*0.81 | 2.48*0.83*1.99 | 24v/3.3kw | 2260 |
| YG0810 | 8 | 450 | 2.27*1.12 | 2.48*1.19*1.78 | 24v/3.3kw | 2360 |
| YG1012 | 10 | 320 | 2.27*1.12 | 2.48*1.19*1.91 | 24v/3.3kw | 2640 |
| YG1214 | 11.8 | 320 | 2.27*1.12 | 2.48*1.19*2.03 | 24v/4.5kw | 2980 |
| YG1416 | 13.7 | 230 | 2.64*1.12 | 2.85*1.25*2.105 | 24v/4.5kw | 3600 |
Off-Road Performance: Quantifying Gradeability and Safe Tilt
The core advantage of tracked design is superior mobility.
- Gradeability: Our standard 8m tracked motorized scissor lift features approximately 30° gradeability. This allows it to climb steep ramps and slopes easily.
- Safe Tilt: In specific models, the tracked lift can operate safely on a longitudinal slope of 15°.
- Always ensure your equipment maintains safe operation on challenging terrains.
Minimal Impact: Low Ground Pressure for Sensitive Sites
The tracks are crucial for protecting sensitive ground. This is unique to the tracked scissor lift for sale.
- Ground Pressure: Our tracked platforms typically have an average ground pressure of about 5 psi.
- When it comes to wheeled all-terrain scissor lifts for sale, many models can exert up to 10 PSI.
- Lower pressure means you can work on grass, historical sites, or paved areas without leaving deep marks. The track width is typically 250 mm.
Safety Assurance: Integrated Self-Leveling System and Lift Stability
Working on uneven surfaces makes lift stability non-negotiable.
- Tracked platforms include an integrated self-leveling system. This system automatically corrects the platform angle in under 5 seconds.
- This rapid leveling ensures the 1.5x safety factor is maintained during high-altitude operation.
- The self-leveling feature is the lifeline for tracked equipment operating on rough terrain.
Power Options: Diesel Engine Power vs. Electric Drive
The power source impacts the performance of your all-terrain scissor lift for sale.
- Diesel: Provides raw engine power and continuous runtime. It is best suited for large, remote rough terrain sites.
- Electric: Ideal for semi-open sites with strict noise and emission regulations.
- Choosing diesel ensures stable platform capacity 350kg even at the $14 \text{m}$ maximum working height.
Versatility: The Tracked Mobile Hydraulic Lift Platform
Tracks significantly expand the capability of a traditional mobile hydraulic lift platform.
- The tracked chassis allows platforms ranging from 8m to 14m to access previously unreachable areas.
- The standard platform size is approximately 2.1m*1.1m. This provides ample working space.
- This enhanced mobile hydraulic lift platform is ideal for construction, agriculture, and industrial maintenance.
Application Expansion: Infrastructure, Landscaping, and Energy
The tracked scissor lift for sale has wide use in specialized fields.
- Infrastructure: Used for bridge inspection or transmission line maintenance, leveraging its high gradeability.
- Landscaping/Agriculture: In orchards or general landscaping, low ground pressure protects soil and vegetation.
- Energy: Provides necessary lift stability for solar or wind facility installation in remote, mountainous areas.
Success Case: Boosting Site Efficiency for David in the USA
David is a utility contractor in the Western United States. His challenge was installing piping on muddy, unpaved job sites.
- The Problem: Wheeled lifts frequently got stuck. He spent 2 full days laying down ground protection mats.
- The Solution: David purchased a 10m tracked scissor lift for sale. The machine boasts a low ground pressure of 5 PSI.
- The Outcome: He completely eliminated the need for ground mats. This saved 2 days of preparation time and reduced his project cost by 12%. He was highly satisfied with the stability and self-leveling efficiency of the tracked lift on rough terrain.
Buying Decision: Tracked vs. Wheeled
How should a customer choose between a tracked and wheeled all-terrain scissor lift for sale?
- Tracked: Maximum height is generally 14m. The primary considerations are ground pressure and gradeability.
- Wheeled (Motorized Scissor Lift): The Maximum height can reach 18m. It is best for flat, semi-paved outdoor sites.
- If 80% of your work involves rough terrain, the tracked model is the superior choice.
Your Tracked Scissor Lift for Sale Expert
The tracked scissor lift for sale provided by YG Machinery is the ideal combination of rough terrain capability and aerial access. We focus on delivering superior lift stability, low ground pressure, and 30% gradeability. We meet your mobile hydraulic lift platform needs in the most demanding environments.
Contact YG Machinery today for a free site suitability assessment and find the perfect all-terrain scissor lift for sale solution for your next challenging project!
