How can you handle oversized glass safely and efficiently in modern construction? The answer lies in using a glass sucker machine, which is the perfect solution for this task. At YG Machinery, a top global manufacturer, we create equipment specifically designed to enhance productivity on job sites. With load capacities ranging from 300kg to 800kg, our machines not only significantly cut down on labor costs but also ensure that operational safety meets industrial-grade standards.
Glass Sucker Machine Parameter:
| Model Type | YG-LD-300 | YG-LD-400 | YG-LD-500 | YG-LD-600 | YG-LD-800 | |
| Load Capacity | 300kg(retract)150kg(extend) | 400kg(retract)200kg(extend) | 500kg(retract)250kg(extend) | 600kg(retract)300kg(extend) | 800kg(retract)400kg(extend) | |
| Lifting Height | 3500mm | 3500mm | 3700mm | 3700mm | 4500mm | |
| QTY of Suction Cap | 4pcs | 4pcs | 6pcs | 6pcs | 8pcs | |
| Rubber Suction Cap | 300mm | Ø300mm | Ø300mm | Ø300mm | Ø300mm | |
| Maintenance-free Battery | 2x12V/80AH | 2x12V/100AH | 2x12V/120AH | 2x12V/120AH | 2x12V/120AH | |
| Battery Charger | Smart Charger | Smart Charger | Smart Charger | Smart Charger | Smart Charger | |
| Drive motor | 24V/1200W | 24V/1200W | 24V/1200W | 24V/1200W | 24V/1200W | |
| Lifting Motor | 24V/2000W/6L | 24V/2000W/6L | 24V/2000W/6L | 24V/2000W/6L | 24V/2000W/12L | |
| Chassis L*W | 2660*810mm | 2660*810mm | 2800*810mm | 2800*810mm | 2800*810mm | |
| Driving Wheel | Ø250x80mm | Ø250x80mm | Ø300x100mm | Ø300x100mm | Ø300x125mm | |
| Packing Size(mm) | 2560*1030*1700 | 2560*1030*1700 | 2580*1050*1700 | 2580*1050*1700 | 3000*1250*2300 | |
| N.W/G.W | 1100/1150kg | 1280/1330kg | 1300/1350kg | 1400/1450kg | 1600/1650kg | |
| Loading Qty | 1x20GP/40GP: 6SETS/12SETS | |||||
| Movement | Automatic(4 kinds) | 1. The suction cup frame flips 180° electrically. 2. The support plate automatically retracts. 3. Hydraulic arm lifts electrically. 4. The base of the whole machine moves 100-150mm horizontally. | ||||
| Manual (2kinds) | 1. The suction cup holder can be manually rotated 90 degrees (electrically powered optional). 2. The suction cup holder can be manually rotated 360 degrees (electrically powered optional). | |||||
| Usages | Mainly used for the handling, movement, and installation of materials such as glass, marble, wood, iron plate, etc. | |||||
What Is a Professional Glass Sucker Machine?
A professional glass sucker machine is far more than a simple lifting tool. It integrates high-precision vacuum sensing technology with flexible mechanical control. For contractors searching for a glass lifting machine for sale, YG provides more than just equipment; we offer a complete logistics solution. Our machines feature a one-piece molded aluminum alloy body, ensuring a structure that is both strong and naturally rust-resistant, perfect for diverse outdoor environments.
Core Technical Advantages of YG Glass Sucker Machines
- Double Circuit Vacuum System: Driven by DC power and equipped with a double circuit system. Even in the event of an unexpected power failure, the built-in vacuum accumulator ensures pressure is maintained, allowing ample time for emergency response.
- Imported Silicone Suction Cups: YG utilizes high-quality imported silicone, which offers stronger adsorption and anti-aging properties, adapting to long-term operations in extreme weather.
- Smart Handle Control: The integrated smart handle provides real-time displays of main power and battery levels, keeping operators fully informed of the machine’s status.
- All-around Flexibility: The suction frame supports 360° rotation and 180° side tilting. Paired with a thickened telescopic boom, it easily handles complex angle requirements.
Why Safety Must Be Your Priority in Glazing Lifting Equipment?
When operating glazing lifting equipment, even a tiny vacuum leak can lead to catastrophic results. YG never compromises on safety. Our machines are equipped with a sensitive safety alarm device and additional support legs on both sides to ensure the equipment runs more stably during movement and lifting. This attention to detail makes our glass panel lifting equipment the first choice for major international projects.
Wide Range of Applications for Glass Panel Lifting Equipment
YG’s glass panel lifting equipment has been widely adopted across various sectors due to its exceptional adaptability:
- High-rise Curtain Walls: Precise installation of large-scale tempered glass at height.
- Heavy Stone Handling: Effortlessly moving high-density materials like granite and marble.
- Industrial Workshops: Used for the internal turnover of flat, dense materials such as steel and aluminum plates.
- Interior Decoration: Thanks to the effortless electric walking function, it completes large mirror installations in confined indoor spaces.
Success Case: How a UK Contractor Saved 40% in Labor Costs
Mr. Oliver, a building contractor from London, UK, faced immense schedule pressure during a large shopping mall project. He solved this problem by purchasing a YG glass sucker machine.
Before introducing this equipment, installing a 500kg curtain wall glass required six skilled workers. Using YG’s glass panel lifting equipment, only one operator and one assistant were needed. Mr. Oliver stated: “The YG machine has powerful thrust and is extremely easy to flip, which increased our construction speed by nearly 50% while achieving a zero-damage rate.”
FAQ About Glass Sucker Machine for Sale
Yes. Each of our suction cups has an independent vacuum control valve, making maintenance easy and allowing you to choose how many cups to activate based on the panel size.
Yes. We are equipped with wear-resistant outdoor drive wheels and high-power motors. The power is strong enough to drive stably even on the complex ground of construction sites.
As a veteran glass lifting machine for sale supplier, YG Machinery provides comprehensive technical support and spare parts supply to ensure your project remains uninterrupted.
Choose YG to Accelerate Your Projects
Investing in a high-quality glass sucker machine is a long-term strategy to enhance your company’s competitiveness. YG Machinery is committed to combining cutting-edge technology with ultimate safety, helping global customers reduce labor intensity and improve profitability. Whether you need to install complex curtain walls or move heavy stones, we have the perfect solution for you.
Ready to boost your construction efficiency? Contact YG Machinery today for a free technical proposal and the most competitive quote. Let us be the partner in your business success!
